The Switching Power Supplies of The TIS Series

Product Introduction With the UDS module the Traco Power supplier can be extended to a perfect DC-UPS with automatic battery- backup. This function is very often required in applications where a time delayed shutdown of a system is necessary. To monitor and control the power supply a signal module can be installed. For parallel operation with active power sharing a redundancy option is available. This flexibility makes the TIS series power supplies a cost effective solution for many industrial applications. SPECIFICATIONS Output Voltage: 24 VDC Output Adjustment 1: 24-28 VDC Output Current: 6000 mA Power Rating: 150 W Number of Output: single Input Voltage: 93-132 and 187-264 VAC Housing Type: Metal Case Mounting Type: DIN-Rail Mount Connection Type: Screw Terminal Length: 157 mm Width: 56.7 mm Depth: 114.6 mm Efficiency: 85 % Maximum Temperature: 70 °C Minimum Temperature: -25 °C Weight: 800 g Ripple and Noise: 50 mVp-p max. Remote On/Off: No Safety Approvals: EN 60950-1, EN 62368-1, UL 508 Insulation System: Reinforced Insulation I/O Isolation Voltage: 3000 VDC We, a Industrial Control Instrument supplier, also offer the following products, such as ISOPAD, Reotemp, SPONSLER and so on. Welcome to get in touch with us, as a Special equipment and dedicated accessories distributor, Bingde is prepared to help you with qualified products.
